USB on-the-go high-speed (OTG_HS)
Bit 3 STUP: SETUP phase done
Bit 2 AHBERR: AHB error
Bit 1 EPDISD: Endpoint disabled interrupt
Bit 0 XFRC: Transfer completed interrupt
OTG_HS device IN endpoint 0 transfer size register (OTG_HS_DIEPTSIZ0)
Address offset: 0x910
Reset value: 0x0000 0000
The application must modify this register before enabling endpoint 0. Once endpoint 0 is
enabled using the endpoint enable bit in the device control endpoint 0 control registers
(EPENA in OTG_HS_DIEPCTL0), the core modifies this register. The application can only
read this register once the core has cleared the Endpoint enable bit.
Nonzero endpoints use the registers for endpoints 1–15.
31 30 29 28 27 26 25 24 23 22 21
Reserved
Bits 31:21 Reserved, must be kept at reset value.
Bits 20:19 PKTCNT: Packet count
Bits 18:7 Reserved, must be kept at reset value.
Bits 6:0 XFRSIZ: Transfer size
1184/1381
Applies to control OUT endpoints only.
Indicates that the SETUP phase for the control endpoint is complete and no more back-to-
back SETUP packets were received for the current control transfer. On this interrupt, the
application can decode the received SETUP data packet.
This is generated only in internal DMA mode when there is an AHB error during an AHB
read/write. The application can read the corresponding endpoint DMA address register to
get the error address.
This bit indicates that the endpoint is disabled per the application's request.
This field indicates that the programmed transfer is complete on the AHB as well as on the
USB, for this endpoint.
20
19
PKTCNT
rw
rw
Indicates the total number of USB packets that constitute the Transfer Size amount of data
for endpoint 0.
This field is decremented every time a packet (maximum size or short packet) is read from
the TxFIFO.
Indicates the transfer size in bytes for endpoint 0. The core interrupts the application only
after it has exhausted the transfer size amount of data. The transfer size can be set to the
maximum packet size of the endpoint, to be interrupted at the end of each packet.
The core decrements this field every time a packet from the external memory is written to
the TxFIFO.
18 17 16 15 14 13 12 11 10
Reserved
RM0033 Rev 9
9
8
7
6
5
4
3
XFRSIZ
rw rw rw rw rw rw rw
RM0033
2
1
0
