10.9.5 Moement for Copy Tray Dievyer

The paper meos while pushign down the plastic sheet, and then moves ahead in the direction of the centra tray.
Immeiately after the trailig edge of the paper moves past the palstc film the momevement stops, at which time the
movmeent rverses so that the paper moves along the plastic sheet in the direction of the copy tray.
Copy tray delivery
Copy tray delivery
Plastic sheet
Paper
movement
reverse
Plastic sheet
F-10-32
Paper
Paper
Chapter 10
0000-4702
10-35
