10.9.2 Movement in the Direction of Face-Down Delivery

After moving thtough the fixing unit, the paper moves along the FU/FD switching flapper now facing downawar; it
then pushes down the plastic sheet to move to the vertical path diecoint for face-down delivery.
Plastic sheet
FU/FD
switching
flapper
F-10-29
Chapter 10
0000-4699
10-33
