Chapter 10

10.6.5 Detecting the Last paper

When the last paper pickup roll rotates, the slit in the roll cuses the output of the last paper sensor (PS9) to beocme
wave-form pusles. The last paper roll rotates only when the last paper is picked up; otherwise, it remains still. The
machine will identify the paper to be the last paper if it detects 4 or more output pules form the lat paper sensor.
10-22
Last paper
Last paper
detecting roll
Last paper
If 4 or more output pulses are detected,
the paper is identified as being the last.
Manual feed lsat paper
sensor (PS9)
Last paper detecting roll
F-10-23
Manual feed
last paper
sensor (PS9)
0000-4692
