Canon iR C3200 Series Service Manual page 990

Chapter 17
Code
E514
E530
E531
E532
17-10
Detail Description
0001 The delivery roller, feed motor
(M2), or feed motor clock sensor
(PI10) is faulty.
0002 The delivery roller, feeder motor
(M2), or feeder motor clock
sensor (PI10) is faulty.
There is a fault in stack processing (clockwise direction).
The stack processing motor (M2)
or the stack delivery lever home
position sensor (S8) is faulty. The
connector is disconnected. The
stack delivery belt or the return
roller is faulty.
There is a fault in alignment.
0001 There is an excess load on the
alignment motor (M3), aligning
plate home position sensor (PI6),
or aligning plate.
0002 There is an excess load on the
rear alignment motor (M3), rear
aligning plate home position
sensor (PI6), or rear aligning
plate.
There is a fault in stapling.
0001 The stapler motor (M6) or the
stapling home position detecting
switch (MS7) is faulty.
0002 The stapler motor (M6) or the
stapling home position detecting
switch (MS7) is faulty.
There is a fault in the shift of the stapler.
0001 The stapler shift motor (M4) or
the stapler shift home position
sensor (PI7) is faulty. There is a
fault in the path of the stapler
shift base.
Timing of detection
The delivery motor clock sensor
fails to generate the target number
of clock pulses within 10 sec at the
start of operation.
There is no clock pulse for a feed
equivalent for 0.2 during
communication.
The stack delivery lever fails to
reach its home position when the
stack processing motor has been
driven for a specific period of time
at start of operation.
The aligning plate does not leave
the aligning plate home position
sensor when the alignment motor
has been driven for 2 sec.
The aligning plate does not return to
its home position when the aligning
plate motor has been driven for 2
sec.
The stapler does not leave the
stapler shift position when the
stapler shift motor has been driven
for 0.5 sec.
The stapler does not return from the
stapler shift position when the
stapler shift motor has been driven
for 0.5 sec.
The stapler shift base does not leave
the stapler shift home position
sensor when the stapler shift motor
has been driven for 4 sec.
