16.3.10.30 E020-0125 Error Code

[ Inspected by Canon Inc. ]
Field Remedy
E020-0125 can be displayed when there is a fault/open circuit in the SALT sensor, a fault in the drum unit, or
the ITB is deteriorated.
As a result of inspection, it was found that a pin of the connector of the SALT sensor was deformed, causing
poor contact. Check whether the pin of the connector is deformed.
16.3.10.31 E020-03B0 Error Code: Overall fogging (no margin) occurred after
replacement of Cyan drum unit
[ Case in the field ]
Field Remedy
There is a case in the field that the DC Controller PCB was faulty.
For your information, when the overall fogging with no margin occurs, there is a high possibility that there is a
problem with the DC controller PCB or the H.V. transformer PCB. On the other hand, if there is a margin, it is
possible that the main controller PCB or the sub controller PCB is faulty.
16.3.10.32 E032 Error code detail The counter of the NE controller fails to
operate.
Symptom
E032 The counter of the NE controller fails to operate. (Error code detail)
Description
Detail
0000
16.3.10.33 E110 Error code detail The operation of the laser scanner motor is
faulty.
Symptom
E110 The operation of the laser scanner motor is faulty.(Error code detail)
T-16-9
Description
The counter function of the NE controller fails to operate.
Timing of detection
Chapter 16
0004-5069
0004-8989
0002-1631
0002-1634
16-137
