Ultrasonic Endoscope
EG-580UT
OPERATION MANUAL
This Operation Manual describes details on how to operate the ultrasonic endoscope and cautions
to be observed when operating it. Please read this manual thoroughly before actually operating the
ultrasonic endoscope.
After reading this manual, store it nearby the ultrasonic endoscope so that you can see it whenever
necessary.
