1.14 Using the A/B Cursors

This section describes how to read values from the measured waveform using the A/B cursors. You
can also use the cursors to specify a range for saving data or performing numerical calculations.

Reading values from the waveforms

This section describes how to read measured values, times, and time differences between cursors

using the A/B cursors.

When using the scaling function, post-scaling values are displayed.
1
Under [Display], set the display to [Wave+Value].
2
Set the display item to [Cursor].
3
Select [ON]
The A/B cursors will be displayed on the screen.
When the Cursor icon is displayed, pressing the any one of the
automatically change the setting to
4
Select the A/B cursor type.
Vertical
Horizontal
*: The instrument expresses minute, a unit of time, included in cursor reading values in terms of the letter m
instead of min.
Find Quality Products Online at:
1 1
10
10
under the A/B cursor settings.
[ON]
Vertical axis cursors
• Times at the A/B cursors*
• Measured values at the intersections of the A/B
cursors and the waveform
• Time lag between the B and A cursors (B-A)*
• Difference in measured values at the B and A cursors
(B-A)
Horizontal axis cursors
B
• Measured values at the A and B cursors
• Difference in measured values at the B and A cursors
A
(B-A)
B-A
GlobalTestSupply
www.
2 2
3 3 4 4
6 6
(1)
(2)
SCROLL/CURSOR
even with the A/B cursors set to [OFF].
B
A
B-A
B-A
A B
B-A
B-A
5 5
7 7
keys will
A B
B-A
B
A
.com
sales@GlobalTestSupply.com
B
A
B-A
