8
Find Quality Products Online at:

External Control (EXT. I/O)

8.1 Configuring Voltage Output (VOUTPUT) ............................p. 2 24
8.2 Configuring Alarm Output (ALARM) ...................................p. 2 25
8.3 Configuring External Input/Output (I/O) Terminals ...........p. 2 27
External trigger input .............................................................................. p. 2 29
Trigger output ......................................................................................... p. 2 30
Simultaneously starting measurement using external triggers ............... p. 2 32
GlobalTestSupply
www.
This chapter describes how to control the instrument by
inputting signals to its external control terminals.
Signals corresponding to the instrument's operation are
output from the external control terminals.
You can configure settings related to the external control
terminals on the [System]
The external control terminals are not isolated (they use the
same ground as the instrument).
For more information about how to connect signals to the
external control terminals, see "External Control Connections"
in the Quick Start Manual.
.com
> [External] settings screen.
