1.4 Configuring Input Channels

Configure input channels for voltage measurement, temperature measurement, etc.
Channel
Input
Range
Set the waveform color, scaling, and comments as necessary.
These settings can be configured either on each channel's individual settings screen or on the
settings list screen for multiple channels.
Setting method
1
Set the main tab to [Channel].
2
Select the settings screen on the sub tab.
• [Individual]
Configure the settings on the individual settings screen for each channel.
• [Unit 1]
Configure the settings on the settings list screen for each module.
[Pulse]
•
Configure the settings on the settings list screen.
3
Press the
The focus will move to the settings area.
You can return the focus to the sub tab by pressing the
4
Select the setting you wish to configure with the
Down Arrow
5
Press the
The available settings will be displayed.
6
Select the desired setting with the
ENTER
The setting will be accepted.
