Torsional stress

Gage method
2-gage method
(adjacent side)
(torsion strain)
4-gage method
(torsion strain)
Find Quality Products Online at:
Bridge circuit diagram
Applied voltage
E
e = 2ε
Applied voltage
E
e = 4ε
Even in measurements that are affected by temperature, you can compensate for temperature
by using a self-temperature-compensated strain gage. Longer wires are more susceptible
to the effects of temperature. Long wiring runs make lead wires susceptible to the effects of
temperature. You can make measurements with a high degree of precision by using wireless
modules to shorten wiring lengths.
For information about self temperature-compensated strain gages, contact your strain gage's
manufacturer.
GlobalTestSupply
www.
When measuring strain in the rotational direction,
Output
two strain gages are offset so that they intersect
voltage
at an angle of 90°. Use a scaling conversion ratio
e
slope of 1/2.
Rg Rg
1
This connection method is not affected by
temperature changes of the measurement target or
Output
tension/compression/bending strain. Use a scaling
voltage
conversion ratio slope of 1/4.
e
Rg
4
Rg
2
Rg
1
.com
