Hioki MEMORY HiLOGGER LR8450 Instruction Manual page 302

Continuous operating
time
Charging functionality Charging is available when the Z1007 Battery Pack is attached and the AC Adapter is
-4. Interface specifications
The LAN interface and USB interface (function) cannot be used at the same time.
LAN interface
Find Quality Products Online at:
Battery With one Z1007 Battery Pack: Approx. 2 h
With two Z1007 Battery Packs: Approx. 4 h
Conditions: With one U8551 Universal Unit connected, backlight
connected.
Charging time: Approx. 7 h (reference value at 23°C)
LAN IEEE 802.3 Ethernet, automatic 100Base-TX/1000Base-T
detection
Auto MDI-X, DHCP, DNS support
Connector RJ-45
Maximum cable length 100 m
LAN functionality Acquiring data and setting recording conditions with the Logger
Utility
Configuring settings and controlling recording using
communications commands
Manually acquiring data using the FTP server
Acquiring files from a connected SD Memory Card or USB Drive
Automatically sending data via FTP (FTP client)
Transferring files saved on a connected SD Memory Card or
USB Drive
While measurement is in progress: Waveform files (binary, text,
After measurement has finished: Waveform files (binary, text,
HTTP server function
Control mode (one instrument)
Displaying screen and remotely controlling instrument and
modules, displaying current measured values, starting/
stopping measurement, acquiring data via FTP, configuring
comment, updating instrument and modules
Browsing mode (up to four instruments)
Displaying screen, current measured values, measurement
status, and comments
Email transmission
The instrument will send emails at a regular interval and at the
following events: start trigger, stop trigger, alarm, power outage
recovery, internal buffer memory full, media full, wireless unit
communications interruption, and battery low.
Attachment of instantaneous value data can be enabled or
disabled.
Emails can be sent regularly at the following intervals: 30 min.,
1 h, 12 h, 1 day.
XCP on Ethernet
Measurement mode XCP Slave function support only
ASAM e.V. MCD-1 XCP v 1.5.0 compliant
NTP client function
Time synchronization with an NTP server
Regular synchronization intervals: 1 h, 1 day
Pre-measurement synchronization function
GlobalTestSupply
www.
(reference value at 23°C)
(reference value at 23°C)
on, voltage output off, and Z4006 connected
MDF)
MDF), numerical calculation
result files
