Trigger Function

2.1 Trigger Meanings ..................................................................p. 1 15
2.2 Enabling the Trigger Function .............................................p. 1 16
2.4 Logic Triggers (Patterns) .....................................................p. 1 24
2.5 CAN Trigger...........................................................................p. 1 26
2.7 Activating a Trigger at a Set Interval ..................................p. 1 30
2.8 Forcibly Activating the Trigger ............................................p. 1 32
2.9 Example Trigger Settings ....................................................p. 1 33
GlobalTestSupply
www.
Triggers provide functionality for starting and stopping
measurement based on specific conditions and signals.
When a specific condition (a trigger condition) occurs, the
trigger is said to activate.
The points at which triggers activate (i.e., the points in time
at which trigger conditions are satisfied) are known as trigger
points, which are identified by the
When a trigger activates, you can start or stop recording.
Trigger sources can be selected from among the following:
• Analog triggers (level, window)
• Pulse (level, window)
• Logic triggers (condition, pattern)
• Waveform calculation (level, window)
• CAN (level, window, logic)
• Interval triggers
• External triggers
