Hioki MEMORY HiLOGGER LR8450 Instruction Manual page 64

3
(When the scaling conversion method is set to [Ratio])
Enter the slope and the offset in
Select the numerical value entry item and press the
setting window.
See "Value entry method" (p. 9 ).
−9.9999e+09
Example setting
Make measurements using a differential probe with a division ratio of 1/100 and display waveform
data as values expressed in units of volts (V):
Unit
Slope
Offset
4
Enter the post-conversion unit in
See "Text entry method" (p. 1 0).
5
(When the scaling conversion method is set to [2-point])
Enter the pre- and post-conversion values in
Select the numerical value entry item and press the
setting window.
−9.9999e+29
Example setting
Convert 4-20 mA output from a sensor into 0 to 100 mm.
The 4-20 mA output is measured as 1 V to 5 V using a 250
Convert a range of 1 V to 5 V into that of 0 mm to 100 mm.
Unit
Convert 1
Convert 2
6
(When the scaling conversion method is set to [Sensitivity])
Enter the sensitivity value in [Sensitivity].
Select the numerical value entry item and press the
setting window.
−1.0000e+09
Example setting
Make measurements using a heat flow sensor with a sensitivity constant of 0.02421 mV/W•m
display waveform data as values expressed in units of watts per square meter (W/m
Unit
Sensitivity
Offset
Find Quality Products Online at:
[Slope]
to +9.9999e+09
V
100
0
[Unit]
to +9.9999e+29
mm
Convert 1 into 0 (1 V into 0 mm).
Convert 5 into 100 (5 V into 100 mm).
to +1.0000e+09
W/m 2
0.02421 m (displayed as 24.21 μ)
0
GlobalTestSupply
www.
and [Offset], respectively.
ENTER key to display the numerical value
(up to 7 single-byte characters).
[Convert 1] and [Convert
ENTER key to display the numerical value
Ω
shunt resistor.
ENTER
key to display the numerical value
.com
Using the Scaling Function
2], respectively.
-2 and
2
):
