Hioki MEMORY HiLOGGER LR8450 Instruction Manual page 307

Basic Specifications
4. Files
-1. Saving
Save destinations
Filenames
Auto saving
Find Quality Products Online at:
SD Memory Card/USB Drive (user-selectable)
Up to 8 single-byte characters
Automatic numbering, adding date and/or title comment (user-selectable)
Waveform data (real-time saving)
Off, binary format, text format, or MDF format (user-selectable)
Numerical calculation results (saved after recording)
Off or text format (user-selectable)
When text format is selected, the user can choose whether to save all calculations
in one file or to save each calculation in its own file.
Priority save SD Memory Card/USB Drive (user-selectable)
destination The user can choose whether to give priority to the SD Memory
Card or the USB Drive for saving data when both are inserted.
Delete and save On/Off (user-selectable)
Off: The system will stop saving data when the SD Memory
On: When the SD Memory Card or USB Drive starts to run
Folder splitting Disabled, 1 day, 1 week, or 1 month (user-selectable)
File splitting Disabled, enabled, or timed (user-selectable)
Disabled: Data for each recording session is saved in its own
Enabled: Data for each set period of time is saved in its own
Split time: Day, hour, or minute (user-selectable)
Timed:
Reference time: Set in hours and minutes.
Split time:
External media eject External media can be ejected during real-time saving by
(SD Memory Card/ activating a button on the screen and confirming a message.
USB Drive) • When both an SD Memory Card and a USB Drive are inserted
and the media set as the priority save destination is ejected,
the system will continue to save data on the other media.
• When either an SD Memory Card or a USB Drive is inserted
and the media set as the priority save destination is ejected,
the system will stop saving data. If external media is reinserted
under these conditions, the system will continue saving data
remaining in the internal buffer memory to a different file.
Data protection Yes (valid only when the Z1007 Battery Pack is installed)
If the remaining battery life declines during real-time saving,
the system will close the file and stop saving data (although
measurement operation will continue).
GlobalTestSupply
www.
Card or USB Drive starts to run out of available space.
out of available space, the system will delete the oldest
waveform file (binary, text, or MDF) and then continue
saving data. When both an SD Memory Card and a USB
Drive are inserted, the system will perform delete and
save on the media that has been set as the priority save
destination only.
file.
file, starting with the start of measurement.
Data will be segmented at intervals of the segment
time based on the previously set reference time and
saved in separate files.
1 min, 2 min, 5 min, 10 min, 15 min, 20 min,
30 min, 1 h, 2 h, 3 h, 4 h, 6 h, 8 h, 12 h, 1 d
