Enabling the Trigger Function
Relationship between pre-triggers and recording time
If the recording time is shorter than the
pre-trigger
Pre-trigger
(15 min.)
Find Quality Products Online at:
Measurement will
stop when the
trigger activates.
Measurement
start
Recording time
(10 min.)
GlobalTestSupply
www.
If the recording time is longer than the
pre-trigger
Data will be
measured before
and after the trigger.
Measurement
start
Pre-trigger
(5 min.)
.com
Measurement
will stop at the
recording time.
Recording time
(15 min.)
