Lr8532 Wireless Voltage/Temp Unit - Hioki MEMORY HiLOGGER LR8450 Instruction Manual

LR8532 Wireless Voltage/Temp Unit

1. General specifications
Compatible logger
Communication
means for control
Communication
buffer memory
Operating
environment
Operating
temperature and
humidity range
Storage temperature
and humidity range
Standards
Standard compliance
Vibration resistance
Power supply
Continuous operating
time
Charging
functionality
Dimensions
Weight
Product warranty
duration
Accessories
Find Quality Products Online at:
LR8450-01 Memory HiLogger
With the Z3230 Wireless LAN Adapter (accessory) attached, wirelessly communicate to
the LR8450-01.
4 Mwords (volatile memory)
If a communication error occurs, data can be retained. The retained data will be resent
after the communications recover.
Indoor use, pollution degree 2, altitude up to 2000 m (6562 ft.)
−20°C to 55°C (−4°F to 131°F), 80% RH or less (non-condensing)
(Charging temperature range: 5°C to 35°C)
−20°C to 60°C (−4°F to 140°F), 80% RH or less (non-condensing)
Safety EN 61010
EMC EN 61326 Class A
Thermocouples: JIS C1602:2015, IEC 60584-1:2013
JIS D 1601:1995 5.3 (1)
Class 1: Passenger vehicles; conditions: Class A equivalent
(4 h along X-axis and 2 h along Y- and Z-axes at a vibration acceleration of 45 m/s
• Z1008 AC Adapter (12 V DC)
Rated supply voltage: 100 V to 240 V AC (assuming ±10% voltage fluctuation of the
rated supply voltage)
Rated power supply frequency: 50 Hz/60 Hz
Anticipated transient overvoltage: 2500 V
Maximum rated power: 25 VA (including AC Adapter)
Normal power consumption: 2.5 VA (instrument only, with the battery removed)
• Z1007 Battery Pack (When used with AC Adapter, AC Adapter has priority.)
Rated supply voltage: 7.2 V DC (Li-ion 2170 mAh)
Maximum rated power: 1.5 VA
• External power supply
Rated supply voltage: 10 V to 30 V DC
Maximum rated power: 8 VA (external power supply 30 V DC, while charging battery)
Normal power consumption: 2.5 VA (external power supply 12 V DC, with the battery
removed)
When using the Z1007 Battery Pack
Approx. 9 h (all data refresh intervals, communications in good condition, reference value
at 23°C)
Charging is available when the Z1007 Battery Pack is attached and either the AC Adapter
or an external power supply (10 V to 30 V DC) is connected.
Charging time: Approx. 7 h (reference value at 23°C)
Approx. 154W × 106H × 57D mm (6.06"W × 4.17"H × 2.24"D) (including cover)
Approx. 388 g (13.7 oz., including Z3230 Wireless LAN Adapter)
3 years
Z3230 Wireless LAN Adapter
Instruction Manual
Z1008 AC Adapter (3-prong grounded-type [2-pole] power cord)
Mounting plate
M3×4 screws ×2 (for the mounting plate)
