Under [Filter], select the cutoff frequency.
Auto
When
in the following table based on the set data refresh interval:
Data refresh interval
6
On the
right of the screen.
Auto-balancing will be performed for all channels of the Strain Unit.
Perform this step under the following conditions:
• Turn on the instrument and wait 30 minutes.
• Connect a strain gage or strain gage-type converter to the module; however, do not apply any
loads, including vibration.
• Connect the B and D inputs terminals with one another when measuring voltage.
Auto-balancing cannot be performed while measurement is in progress.
Key operations are ignored while auto-balancing is in progress.
Perform auto-balancing again in the following circumstances:
• When the input types have changed
• When the range has changed
• When module connections have changed
• When the strain gage or strain gage-type converter has changed
• When the instrument's power has been cycled
• When the instrument's settings have been initialized
• When the ambient temperature has changed abruptly (when the zero position may have drifted)
If auto-balancing fails, check the following:
• Is the strain gage or strain gage-type converter in a no-load state?
• Is the strain gage or strain gage-type converter connected properly?
Find Quality Products Online at:
, 120 Hz, 60 Hz, 30 Hz, 15 Hz,

[Auto] is selected, the low-pass filter's cutoff frequency will automatically be set as described
Cutoff frequency
1 ms
2 ms
5 ms
10 ms
20 ms
50 ms
100 ms
[Wave+Set] screen, press the
Auto-balancing can also be performed using the
button on the top right of the channel list screen. Press the
key to display the settings window.
Select the check boxes for the channels for which you wish to
perform auto-balancing. Then press the
is selected.
Press the
auto-balancing for all channels at once.
See "1.9 Configuring Channels in a List" (p. 6 7).
