Text Format
*2: Outputted according to the measurement target as follows:
Voltage (Voltage), thermocouple (Tc), resistance temperature detector (Rtd), humidity (Humidity),
resistance (Resistance), strain (Strain), count (Count), revolving speed (Revolve), logic (Logic),
alarm (Alarm), alarm source (Alarm Source), waveform calculation (Calculation), and CAN.
*3: Outputted according to the measured data type as follows.
Data type
Analog
Pulse, waveform
calculation
CAN
Logic
Alarm
Alarm source
CAN disabled flag
Event mark
*4: Varies depending on the data type
Data type
Analog, pulse,
waveform calculation
Logic
Break in
thermocouple,
communication error,
low battery
Find Quality Products Online at:
Exponential notation (six significant figures)
Exponential notation (10 significant figures)
Exponential notation (10 significant figures)
0: Low, 1: High
0: Not issued, 1: Issued
Hexadecimal notation (blank character when no alarm is issued)*
Hexadecimal notation
00H: Normal
01H: Unit 1 data error
02H: Unit 2 data error
04H :Unit 3 data error
08H: Unit 4 data error
10H: Remote 1 data error
20H: Remote 2 data error
40H: Remote 4 data error
80H: Remote 5 data error
100H: Remote 6 data error
200H: Remote 7 data error
0: No mark assigned, 1 or greater: Marks assigned
Alarm onset statuses are outputted with channels assigned to each bit. (CH1
is assigned to the most significant bit [MSB].) An analog output and waveform
calculation output are represented by eight characters (32 bits); pulse output and
logic output are represented by two characters (8 bits). The letter H is added at the
end.
Example: When U1-1 issues an alarm, the alarm source output is represented by
0x80000000H.
When a channel generates an alarm the output is represented by 1; otherwise,
represented by 0. No letter is added at the end.
Example: When a logic channel issues an alarm, the output is represented by 1.
An alarm source output is represented by 12 characters (11 modules and a spare
bit), in which a character (4 bits) is assigned to each module with an alarm status
incorporated.
A break in a thermocouple, communication error, and low battery state are in order
beginning from the MSB (for plug-in modules, broken thermocouple only). The letter
H is added at the end.
Example: When broken thermocouples are found in U2 and U4, the output is
represented by 0x080800000000H.
