Hioki MEMORY HiLOGGER LR8450 Instruction Manual page 301

Basic Specifications
Dimensions
Weight
Standards
Vibration resistance
-2. Display
Display
Display resolution
(with waveform
display selected)
Display language
Backlight service life
Backlight saver
Backlight brightness
Waveform background
color
-3. Power supply
Power supply
Power consumption
Find Quality Products Online at:
Without any modules: 272W × 145H × 43D mm (10.72"W × 5.71"H × 1.69"D)
(excluding protrusions)
With 2 modules: 272W × 198H × 63D mm (10.71"W × 7.8"H × 2.78"D)
(excluding protrusions)
With 4 modules: 272W × 252H × 63D mm (10.71"W × 9.92"H × 2.48"D)
(excluding protruding parts)
Approx. 1.1 kg (38.8 oz.)
Safety EN 61010
EMC EN 61326 Class A
JIS D 1601:1995 5.3 (1)
Class 1: Passenger vehicles; conditions: Class A equivalent
(4 h along X-axis and 2 h along Y- and Z-axes at a vibration acceleration of 45 m/s
[4.6 G])
7-inch TFT color LCD (WVGA 800 × 480 dots)
Max. 20 divisions (horizontal axis) × 10 divisions (vertical axis)
(1 division = 36 dots [horizontal axis] × 36 dots [vertical axis])
Japanese/English/Simplified Chinese/Traditional Chinese/Korean (user-selectable)
Approx. 100,000 h (reference value at 23°C)
Turns off backlight when no key is operated for a set amount of time.
(Choose from Off, 30 s, 1 min., 2 min., 5 min., 10 min.)
5 levels (user-selectable)
Dark/light (user-selectable)
AC adapter Z1014 AC Adapter (12 V DC ±10%)
AC Adapter rated supply voltage
AC Adapter rated power supply frequency
Battery The instrument accommodates two batteries.
Z1007 Battery Pack
(When used with AC Adapter, AC Adapter has priority.)
Li-ion, 7.2 V, 2170 mAh
External power supply 10 V to 30 V DC
Normal power Using Z1014 AC Adapter or 12 V DC external power supply,
consumption without Battery Pack
With LCD at maximum brightness: 8.5 VA (instrument only)
With LCD backlight off: 7 VA (instrument only)
Maximum rated power When using the Z1014 AC Adapter
When using a 30 V DC external power supply
When using the Z1007 Battery Pack
GlobalTestSupply
www.
100 V to 240 V AC (assuming voltage fluctuation of
±10%)
50 Hz/60 Hz
95 VA (including AC Adapter)
28 VA (while charging battery with LCD at maximum
brightness)
20 VA (with LCD at maximum brightness)
