Hioki MEMORY HiLOGGER LR8450 Instruction Manual page 85

Observing Waveforms
No.
10 10
11 11
12 12
13 13
14 14
15 15
16 16
17 17
18 18
19 19
20 20
21 21
22 22
23 23
24 24
25 25
26 26
27 27
*1: For more information about icons other than the scroll and cursor icons, see "Screen and icons" in "1.2 Part
Names and Functions; Screens" in the Quick Start Manual.
*2: The waveform screen, value screen, and warning screen of the instrument express minute, a unit of time,
in terms of the letter m instead of min.
Find Quality Products Online at:
Name
Channel selection Allows you to select the channel to configure.
Measurement Allows you to turn measurement on or off.
Waveform color Allows you to select the waveform display color.
Input type Allows you to select the type of input.
Range
Allows you to select the range.
Display position
Allows you to select the waveform display position.
Zoom factor Allows you to select the zoom factor in the voltage axis
direction.
Zero position
Allows you to set the waveform's display position (zero
position).
Zero adjustment Allows you to perform zero adjustment.
Auto-balancing
Allows you to perform auto-balancing (Strain Units only).
Gage B
Indicates the channels and modules displayed using gage
B.
Gage A Indicates the channels and modules displayed using gage
A.
Trigger time Indicates the time and date at which the trigger was
activated.
Status bar Displays the time and date, messages, icons*
information.
Time value Displays the time from the measurement start.*
Scroll bar Indicates the displayed waveform's range and position.
Scroll icon The waveform is moved using the
keys.
Cursor icon The A/B cursors are moved using the
keys.
Follow
The most recent waveform is always displayed using the
auto-scroll function.
GlobalTestSupply
www.
Description
1 , and other
2
SCROLL/CURSOR
SCROLL/CURSOR
.com
sales@GlobalTestSupply.com
Reference
page
–
p. 2 8
p. 2 8
p. 2 5
p. 2 5
p. 5 2
p. 5 2
p. 5 2
p. 7 6
p. 3 7
p. 8 5
p. 8 5
–
–
–
p. 9 1
p. 8 9
p. 9 5
–
