11.1 Measuring Temperature

This section provides precautionary information related to thermocouples, which are widely used to
measure temperature.
Choosing the right thermocouple
The following thermocouples can be used with the instrument:
Thermocouple
K and E thermocouples exhibit a physical phenomenon known as short range ordering in which
thermal electromotive force increases gradually from 250°C to 600°C, producing a large error in a
comparatively short period of time (1 h or less). This unavoidable phenomenon is caused by the
device's physical characteristics. Once a thermocouple's thermal electromotive force has increased,
it will not return to its normal value, even if the temperature falls. In order to return to the original
thermal electromotive force curve, the temperature must rise to at least 650°C.
Choose the appropriate thermocouple after checking with the manufacturer.
Error caused by thermocouple heat dissipation
When a thermocouple is applied to a surface, heat dissipates (is conducted) from the measurement
target via the thermocouple. If heat under measurement is excessively conducted through a
thermocouple, the measured value will not reflect the actual temperature.
Of K and T thermocouples, the latter is characterized by higher heat dissipation due to its superior
thermal conductivity.
The larger the thermocouple's diameter, the greater its heat dissipation.
When measuring the temperature of small components, it is recommended to use a small-diameter
K thermocouple.
Ensuring the thermocouple is securely affixed to the measurement target
To measure temperature with a high degree of precision, ensure that the tip of the thermocouple is
securely affixed to the measurement target.
If the thermocouple junction is insufficiently placed into contact with a measurement target, the
heat cannot conduct to the thermocouple, with the result that the measured value will not reflect the
actual temperature.
When measuring a large measurement target, you can reduce the amount of heat dissipated from
the thermocouple by ensuring that more than just the tip of the thermocouple is in contact with the
measurement target.
