Waveform search

This section describes how to search a measured waveform for a specific point of interest.
This function cannot be used while measurement is in progress.
1
Under [Settings], select [Search].
A number of search-related settings will be displayed.
2
Under [Type], select the search method.
Level
Window
Maximum
Minimum
Maximal
Minimal
3
Under [Area], select the search range.
All data
A-B
4
Under [Target
5
(When
Under [Level], specify the level to search for.
Under [Slope], select the slope (direction in which the waveform crosses the specified level)
to search for.
(When
Under [Upr/Lwr], specify the upper and lower limit values.
Under [IN/OUT], select the direction in which to search (whether the waveform enters [IN] or
exits [OUT] the area defined by the upper and lower limit values).
Find Quality Products Online at:
Searches for points that cross the specified level.
Searches for points that lie inside or outside the window defined by the specified upper
and lower limit values.
Searches for the point at which the maximum value occurs.
Searches for the point at which the minimum value occurs.
Searches for points at which local maximums occur.
Searches for points at which local minimums occur.
Searches all measured waveforms.
Searches the range specified with the A/B cursors.
CH], select the channel to search.
[Type] is set to [Level])
[Type] is set to [Window])
