Auto save (real-time save)

This section describes how to save waveform data (using the real-time save function) to media (an
SD Memory Card or a USB Drive) while measurement is in progress.
Numerical calculation results can also be saved to media automatically.
You can also save both waveform data and numerical calculation results automatically.
The following measurement data can be saved automatically:
Saved data
Waveform data
Numerical
calculation
results
*: If a setting other than
extension is set to [.TXT].
Binary and text format limitations on auto save operation
The number of channels that can be used with auto save operation is limited as shown below
based on the save format and recording interval as well as whether any CAN Units are connected.
Save format
MEM, MDF
Find Quality Products Online at:
Setting
Binary format .MEM
Text format .CSV, .TXT*
MDF format .MF4
Text format .CSV, .TXT*
[Comma] is selected under
Recording interval
1 ms
2 ms
5 ms
10 ms
20 ms
50 ms or longer
1 ms to 5 ms
10 ms
20 ms
CSV 50 ms
100 ms
200 ms
500 ms or longer
GlobalTestSupply
www.
File extension
Waveform data will be saved in the instrument's
dedicated format (binary format) while
measurement continues.
Ordinarily, it is recommended to use the
setting.
Waveform data will be saved in the text format
while measurement continues.
Although the data can be loaded using
spreadsheet software, it cannot be loaded by the
instrument or the Logger Utility.
Waveform data is saved in the MDF (Ver. 4) format
while measurement is ongoing. These files can
be loaded on a PC using a waveform viewer that
supports the MDF format. They cannot be loaded
by the instrument or the Logger Utility.
Numerical calculation results will be saved after
measurement stops.
[Delimiter]
No
Up to 150 channels
No limitations
Auto save setting not available
Up to 60 channels
No limitations
Description
[Binary]
in the [Text format] area, the
CAN Unit(s)
Yes
Up to 20 channels
Up to 80 channels
Up to 150 channels
Up to 700 channels
Up to 1500 channels
No limitations
Up to 100 channels
Up to 200 channels
Up to 500 channels
Up to 1000 channels
Up to 2000 channels
No limitations
