Hioki MEMORY HiLOGGER LR8450 Instruction Manual page 410

>
4
Under
1 1
2 2
3 3
4 4
5 5
6 6
*: To prevent false counting caused by chatter.
You can use the scaling function to convert the pulse count to energy (kWh).
10000 kW
5
Press the
Data will be recorded at a 30 min. interval for 30 days, and waveform data will be saved on the SD
Memory Card.
Recording will stop 30 days after it starts.
If you wish to end recording sooner, press the
Find Quality Products Online at:
>
4 4
[P1] in [Pulse], configure the settings as follows:
Input type Count
Count mode Addition
Slope ↑ (depends on the specifications of watt-meter)
Threshold 1 V (depends on the specifications of watt-meter)
Filter
ON *
Scaling Decimal, 1 kWh = 5000 (5 k), Unit: kWh
0 kW
START key to start measurement.
GlobalTestSupply
www.
1 1
2 2
6 6
STOP
key.
Application Measurement
3 3
4 4
5 5
.com
sales@GlobalTestSupply.com
