Hioki MEMORY HiLOGGER LR8450 Instruction Manual page 342

Terminator
ACT LED
TERM LED
Data refresh interval
Baud rate
Sampling point
ACK
Operating mode
-2. Receive mode specifications
Number of channels
Receive ID count
User frame
transmission
-3. Measured value output mode specifications
Overview
Output target
Output data refresh
period
Response
