3.6 Acquiring Data with a Computer (PC)

This section describes how to use the included USB cable to load data saved on an SD Memory
Card inserted in the instrument onto a computer. "Activating USB drive mode" (p. 1 68)
For more information about how to observe data with the Logger Utility, see the "Communications
Command User Manual" on the included CD. (p. 2 35)
You cannot use the included USB cable to load data stored on a USB Drive inserted in the
instrument. Instead, insert the USB Drive into a USB connector on the computer to load the data.

Connecting the USB cable

Data on an SD Memory Drive can be loaded by computers running the following operating systems:
Windows 7, Windows 8, and Windows 10.
Find Quality Products Online at:
Do not eject the SD Memory Card or unplug the USB cable while data is being
„
transferred.
Doing so may prevent the data from being properly transferred.
Ensure the instrument and computer are grounded at the same potential.
„
Connecting the USB cable while the ground potentials differ between the instrument
and computer could cause the instrument to malfunction or damage it.
Recognized as a removable disk
GlobalTestSupply
www.

Acquiring Data with a Computer (PC)

NOTICE
1
Insert the USB cable's plug into the
instrument's USB cable connector,
exercising care to ensure that the
plug is oriented properly.
2
Connect the other end of the USB
cable to the computer's USB
connector.
The SD Memory Card connected to
the instrument will be recognized as a
removable disk by the computer.
