osd_dout_drv_str, IO Map, Address 0x1BA3H
'This signal is used to control the drive strength for the video output data and sync signals.
Function
osd_dout_drv_str r
00
01
10
11

2.2.2.4. Serial Video Rx

The Serial Video Rx can only be connected to the RX input channel (see

2.2.2.5. Primary Input Channel

The ADV8003 primary input channel incorporates an input formatter, CSC, updither block and ACE control.
The input formatter provides a number of controls to configure what data the video TTL input channel is configured for. The video TTL
input channel must be connected to either the video TTL input pins, the EXOSD TTL input pins or the high speed TTL input pins using
p_inp_chan_sel[1:0]. If the primary input channel is connected to the video TTL input pins, the format and bit width of the data, for
example, 2 x 8 bit buses of 4:2:2 data, must be specified using vid_format_sel[4:0].
input pins are used to carry the upper, middle and lower ranges of bits (for example, upper = D[35:25], middle = D[24:12], lower =
D[11:0] or upper = D[11:0], middle = D[35:25], lower = D[24:12]).
p_inp_chan_sel[1:0], IO Map, Address 0x1A07[1:0]
This signal is used to select the input for the Primary Input Channel.
Function
p_inp_chan_sel[1:0]
00 
01
10
11
vid_format_sel[4:0], IO Map, Address 0x1B48[4:0]
This signal is used to select the input format for the video data.
Rev. B, August 2013
Description
Minimum
Medium low (x2)
Medium high (x3)
High (x4)
Description
Video TTL input (P[35:0])
EXOSD TTL Input (OSD_IN[23:0])
48-bit TTL input (OSD_IN[11:0] and P[35:0]) for 3GHz interleaved TTL
Reserved
Section 2.2.2.7).
vid_swap_bus_ctrl[2:0]
93
ADV8003 Hardware Manual
can be used to indicate which
