Pin
Mnemonic
No.
F20 RSET2
F21 PVDD3
F22 GND
F23 CEC1
G1 OSD_IN[5]
G2 OSD_IN[6]
G3 OSD_IN[7]
G4 OSD_IN[8]
G7 GND
G8 GND
G9 GND
G10 DVDD
G11 GND
G12 GND
G13 DVDD
G14 GND
G15 GND
G16 GND
G17 GND
G20 ELPF1
G21 ELPF2
G22 GND
G23 AVDD3
H1 OSD_IN[1]
H2 OSD_IN[2]
H3 OSD_IN[3]
H4 OSD_IN[4]
H7 GND
H8 GND
H9 GND
H10 GND
H11 GND
H12 GND
H13 GND
H14 GND
H15 GND
H16 GND
H17 GND
H20 GND
H21 GND
H22 TX1_2+
H23 TX1_2−
J1 DE
J2 HS
J3 OSD_HS
Rev. B, August 2013
Type Description
Miscellaneous Resistor Current Setting for Encoder DACs: DAC4, DAC5, and DAC6. Place the RSET
analog resistor as close as possible to the ADV8003.
1
Power PLL Supply (1.8 V).
GND Ground.
HDMI Tx1 HDMI Tx1 Consumer Electronics Control (CEC).
OSD video input External OSD Video Pixel Input Port (OSD_IN[5]).
OSD video input External OSD Video Pixel Input Port (OSD_IN[6]).
OSD video input External OSD Video Pixel Input Port (OSD_IN[7]).
OSD video input External OSD Video Pixel Input Port (OSD_IN[8]).
GND Ground.
GND Ground.
GND Ground.
Power Digital Power Supply (1.8 V).
GND Ground.
GND Ground.
Power Digital Power Supply (1.8 V).
GND Ground.
GND Ground.
GND Ground.
GND Ground.
Miscellaneous External Loop Filter for PLL 1. Connected to PVDD3.
analog
1
Miscellaneous External Loop Filter for PLL 2. Connected to PVDD3.
analog
1
GND Ground.
Power HDMI Analog Power Supply (1.8 V).
OSD video input External OSD Video Pixel Input Port (OSD_IN[1]).
OSD video input External OSD Video Pixel Input Port (OSD_IN[2]).
OSD video input External OSD Video Pixel Input Port (OSD_IN[3]).
OSD video input External OSD Video Pixel Input Port (OSD_IN[4]).
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
HDMI Tx1 HDMI1 Channel 2 True Output.
HDMI Tx1 HDMI1 Channel 2 Complementary Output.
Digital video sync Data Enable for Digital Input Video.
Digital video sync Horizontal Sync for Digital Input Video.
Digital video sync Horizontal Sync for the OSD Input Port (OSD_HS).
