Function
pvsp_demo_window_c
ue_enable
0 
1
pvsp_demo_window_intra_field_enable, Primary VSP Map, Address 0xE87F[4]
This bit is used to enable the intra field interpolation in the demo window.
Function
pvsp_demo_window_in
tra_field_enable
0 
1
The contour-based interpolation scaler (2
pvsp_srscal_demo_mode_en
performance side by side.
pvsp_srscal_demo_mode_en, Primary VSP Map, Address 0xE890[4]
This bit is used to enable scaler demo mode.
Function
pvsp_srscal_demo_mod
e_en
0 
1
3.2.3.15.

Progressive to Interlaced Converter

The main progressive to interlaced (PtoI) converter can be connected to many blocks, for example, Video TTL input channel, EXOSD
TTL input channel, PVSP, and so on. The block can be used for video conversion, for example, conversion of 1080p to 1080i. It drops the
progressive video odd or even lines based on the field signal of the output interlaced video. It can only support 480p, 576p, and 1080p
input. The associated interlaced timing signals can be generated in the independent PtoI hardware block.
By enabling m_p2i_drop_line_as_pvsp_flag, the PtoI module can drop interpolated lines to get optimal output performance.
The PtoI hardware can be enabled using m_p2i_enable.
m_p2i_enable, Secondary VSP Map, Address 0xE649[4]
This bit is used to enable the PtoI in VSP_top.
Function
m_p2i_enable
0 
1
m_p2i_drop_line_as_pvsp_flag, Secondary VSP Map, Address 0xE65B[7]
This bit is used to select an interlaced mode in game mode. If PVSP works in game mode and PVSP's input is interlaced, this bit should
be set to 1 for P2I to drop interpolated lines. Otherwise, this bit should be set to 0.
Rev. B, August 2013
Description
Disable CUE in demo window
Enable CUE in demo window
Description
Disable intra field interpolation in demo window
Enable intra field interpolation in demo window
generation with 4k x 2k support) demo can be enabled by setting
nd
to compare the contour-based interpolation scaler and the frequency-adaptive scaler (1
Description
Scaler not in demo mode
Scaler in demo mode
Description
Disable
Enable
179
ADV8003 Hardware Manual
st generation)
