The effects of selecting between the two adaptive filter modes (using
Rev. B, August 2013
Register
Register Setting
0xE431
0x81
0xE435
0x80
0xE440
0x00
0xE458
0xAC
0xE459
0x9A
0xE45A
0x88
0xE45B
0x28
0xE45C
0x3F
0xE45D
0x64

Figure 118: Input Signal to ED/HD Adaptive Filter

Figure 119: Output Signal from ED/HD Adaptive Filter (Mode A)

Figure 120: Output Signal from ED/HD Adaptive Filter (Mode B)

338
adapt_bc)
can be seen in
Figure 119
ADV8003 Hardware Manual
and
Figure 120.
