Location Mnemonic
D23 DAC2
E1 OSD_IN[13]/VBI_SCK
E2 OSD_IN[14]/VBI_MOSI
E3 OSD_IN[15]/VBI_ CS
E4 DVDD_IO
E20 TEST2
E21 GND
E22 COMP2
E23 DAC3
F1 OSD_IN[9]
F2 OSD_IN[10]
F3 OSD_IN[11]
F4 OSD_IN[12]
F20 RSET2
F21 PVDD3
F22 GND
F23 CEC1
G1 OSD_IN[5]
G2 OSD_IN[6]
G3 OSD_IN[7]
G4 OSD_IN[8]
G7 GND
G8 GND
G9 GND
G10 DVDD
G11 GND
G12 GND
G13 DVDD
G14 GND
Rev. B, August 2013
Type Description if Unused
output
Analog video Float this pin.
output
OSD video Connect this pin to ground through a
input/ 4.7kΩ resistor.
miscellaneous
digital
OSD video Connect this pin to ground through a
input/ 4.7kΩ resistor.
miscellaneous
digital
OSD video Connect this pin to ground through a
input/ 4.7kΩ resistor.
miscellaneous
digital
Power Digital Interface Supply (3.3 V).
Miscellaneous Float this pin.
analog
GND Ground.
Miscellaneous Float this pin.
analog 1
Analog video Float this pin.
output
OSD video Connect this pin to ground through a
input 4.7kΩ resistor.
OSD video Connect this pin to ground through a
input 4.7kΩ resistor.
OSD video Connect this pin to ground through a
input 4.7kΩ resistor.
OSD video Connect this pin to ground through a
input/ 4.7kΩ resistor.
miscellaneous
digital
Miscellaneous Float this pin.
analog 1
Power Encoder PLL Supply (1.8 V).
GND Ground.
HDMI Tx1 Float this pin.
OSD video Connect this pin to ground through a
input 4.7kΩ resistor.
OSD video Connect this pin to ground through a
input 4.7kΩ resistor.
OSD video Connect this pin to ground through a
input 4.7kΩ resistor.
OSD video Connect this pin to ground through a
input 4.7kΩ resistor.
GND Ground.
GND Ground.
GND Ground.
Power Digital Power Supply (1.8 V).
GND Ground.
GND Ground.
Power Digital Power Supply (1.8 V).
GND Ground.
