Analog Devices ADV8003 Hardware Manual page 28

Pin
Mnemonic
No.
L14 GND
L15 GND
L16 GND
L17 GND
L20 HPD_TX1
L21 GND
L22 TX1_C+
L23 TX1_C−
M1 P[28]
M2 P[29]
M3 P[30]
M4 P[31]
M7 GND
M8 GND
M9 GND
M10 GND
M11 GND
M12 GND
M13 GND
M14 GND
M15 GND
M16 GND
M17 GND
M20 R_TX1
M21 PVDD5
M22 HEAC_1+
M23 HEAC_1−
N1 P[24]
N2 P[25]
N3 P[26]
N4 P[27]
N7 GND
N8 GND
N9 GND
N10 GND
N11 GND
N12 GND
N13 GND
N14 GND
N15 GND
N16 GND
N17 GND
N20 CEC2
N21 PVDD5
Rev. B, August 2013
Type Description
GND Ground.
GND Ground.
GND Ground.
GND Ground.
HDMI Tx1 Hot Plug Assert Signal Input for HDMI Tx1.
GND Ground.
HDMI Tx1 HDMI1 Clock True Output.
HDMI Tx1 HDMI1 Clock Complementary Output.
Digital video input Digital Video Input Bus[35:0].
Digital video input Digital Video Input Bus[35:0].
Digital video input Digital Video Input Bus[35:0].
Digital video input Digital Video Input Bus[35:0].
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
HDMI Tx1 Sets Internal Reference Currents. Place a 470 Ω resistor (1% tolerance) between this pin
1
and ground. The external resistor should be placed as close as possible to the
ADV8003.
Power HDMI Tx PLL Power Supply (1.8 V). This pin is a voltage regulator output. Connect a
1
decoupling capacitor between this pin and ground.
HDMI Tx1 HDMI Tx1 HEC+ from HDMI Connector.
HDMI Tx1 HDMI Tx1 HEC− from HDMI Connector.
Digital video input Digital Video Input Bus[35:0].
Digital video input Digital Video Input Bus[35:0].
Digital video input Digital Video Input Bus[35:0].
Digital video input Digital Video Input Bus[35:0].
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
HDMI Tx2 HDMI Tx2 Consumer Electronics Control (CEC).
Power HDMI Tx PLL Power Supply (1.8 V). This pin is a voltage regulator output. Connect a
1
decoupling capacitor between this pin and ground.
28
ADV8003 Hardware Manual
