Function
svsp_vom_crop_width[
10:0]
0x000
0xXXX
svsp_vom_crop_height[10:0], Secondary VSP Map, Address 0xE62C[7:0]; Address 0xE62D[7:5]
This signal is used to set the height of the VOM cropper.
Function
svsp_vom_crop_height[
10:0]
0x000
0xXXX
Note: The following restrictions apply to the values at which these registers can be set:
•
All registers should contain even values
•
0 <=
svsp_vom_crop_h_start[10:0]
•
0 <=
svsp_vom_crop_v_start[10:0]
•
(svsp_vom_crop_h_start[10:0]
•
(svsp_vom_crop_v_start[10:0]
3.3.3.3. Output Port
This section describes the configuration registers for the final block of the VOM of the SVSP. The main purpose of the output port is to
generate the output video timing and output the video data. For more details regarding the various register settings for the output port for
various common video formats, refer to
If the output configuration is to be set manually,
svsp_man_dp_timing_enable, Secondary VSP Map, Address 0xE663[7]
This bit is used to enable manually setting output timing.
Function
svsp_man_dp_timing_e
nable
0
1
svsp_dp_decount[10:0], Secondary VSP Map, Address 0xE632[7:0]; Address 0xE633[7:5]
This signal is used to set the DE duration of output timing. This register's value will be used while svsp_autocfg_output_vid is 0.
Function
svsp_dp_decount[10:0]
0x000
0xXXX
svsp_dp_hfrontporch[9:0], Secondary VSP Map, Address 0xE634[7:0]; Address 0xE635[7:6]
This signal is used to set the horizontal front porch duration of output timing. This register's value will be used while
svsp_autocfg_output_vid is 0.
Rev. B, August 2013
Description
Default
Width of VOM cropper input
Description
Default
Height of VOM cropper input
<= (HORIZONTAL RESOLUTION OUTPUT BY VIM – 1)
<= (RESOLUTION OUTPUT BY VIM – 1)
+ svsp_vom_crop_width[10:0]) <= HORIZONTAL RESOLUTION OUTPUT BY VIM
+ svsp_vom_crop_height[10:0]) <= VERTICAL RESOLUTION OUTPUT BY VIM
Table 34.
The output setting can be automatically configured using svsp_autocfg_output_vid[7:0].
svsp_man_dp_timing_enable
Description
Disable
Enable
Description
Default
Data enable count of output timing
should be set to 1. Refer to
197
ADV8003 Hardware Manual
Figure 66
for more information.
