Analog Devices ADV8003 Hardware Manual page 404

Location Mnemonic
B5 AUD_IN[3]
B6 SFL
B7 ARC1_OUT
B8 MISO1
B9 MOSI2
B10 MISO2
B11 ALSB
B12 XTALP
B13 PVDD1
B14 NC
B15 NC
B16 GND
B17 RX_CP
B18 RX_0P
B19 RX_1P
B20 RX_2P
B21 GND
B22 COMP1
B23 DAC4
C1 OSD_IN[19]/EXT_DIN[3]
C2 OSD_IN[20]/EXT_DIN[4]
C3 GND
C4 AUD_IN[4]
C5 DSD_CLK
C6 SCLK
C7 SCL
C8 SCK1
C9 GND
C10 INT0
C11 PDN
C12 GND
Rev. B, August 2013
Type Description if Unused
4.7kΩ resistor.
Audio input Connect this pin to ground through a
4.7kΩ resistor.
SFL Connect this pin to ground through a
4.7kΩ resistor.
Audio output Connect this pin to ground through a
4.7kΩ resistor.
Serial port Connect this pin to ground through a
control 4.7kΩ resistor.
Serial port Connect this pin to ground through a
control 4.7kΩ resistor.
Serial port Connect this pin to ground through a
control 4.7kΩ resistor.
I 2 C control Connect this pin to ground through a
4.7kΩ resistor.
Miscellaneous This pin must be connected.
digital
Power PLL Analog Supply Voltage (1.8 V).
No connect Float this pin.
No connect Float this pin.
GND Ground.
Rx input Float this pin.
Rx input Float this pin.
Rx input Float this pin.
Rx input Float this pin.
GND Ground.
Miscellaneous Connect this pin to ground through a
analog 1 4.7kΩ resistor.
Analog video Float this pin.
output
OSD video Connect this pin to ground through a
input/ 4.7kΩ resistor.
miscellaneous
digital
OSD video Connect this pin to ground through a
input/ 4.7kΩ resistor.
miscellaneous
digital
GND Ground.
Audio input Connect this pin to ground through a
4.7kΩ resistor.
Audio input Connect this pin to ground through a
4.7kΩ resistor.
Audio input Connect this pin to ground through a
4.7kΩ resistor.
I C control This pin must be connected.
2
Serial port Connect this pin to ground through a
control 4.7kΩ resistor.
GND Ground.
Miscellaneous Connect this pin to ground through a
digital 4.7kΩ resistor.
Miscellaneous This pin must be connected.
digital
GND Ground.
404
ADV8003 Hardware Manual
Pin Type
Digital input
Digital input
Digital output
Digital output
Digital output
Digital Input
Digital Input
N/A
N/A
Digital output
Digital output
N/A
Digital input
Digital input
Digital input
Digital input
N/A
Analog input
Analog output
Bi-directional digital IO
Bi-directional digital IO
N/A
Digital input
Digital input
Digital input
N/A
Digital input
N/A
Digital output
N/A
N/A
