Analog Devices ADV8003 Hardware Manual page 61

K20 NC
K21 GND
K22 NC
K23 NC
L1 P[32]
L2 P[33]
L3 P[34]
L4 P[35]
L7 DVDD
L8 GND
L9 GND
L10 GND
L11 GND
L12 GND
L13 GND
L14 GND
L15 GND
L16 GND
L17 GND
L20 NC
L21 GND
L22 NC
L23 NC
M1 P[28]
M2 P[29]
M3 P[30]
M4 P[31]
M7 GND
M8 GND
M9 GND
M10 GND
M11 GND
M12 GND
M13 GND
M14 GND
M15 GND
M16 GND
M17 GND
M20 NC
M21 PVDD5
M22 NC
M23 NC
N1 P[24]
N2 P[25]
N3 P[26]
N4 P[27]
N7 GND
N8 GND
N9 GND
Rev. B, August 2013
No connect Do not connect to this pin.
GND Ground.
No connect Do not connect to this pin.
No connect Do not connect to this pin.
Digital video input Digital Video Input Bus[35:0].
Digital video input Digital Video Input Bus[35:0].
Digital video input Digital Video Input Bus[35:0].
Digital video input Digital Video Input Bus[35:0].
Power Digital Power Supply (1.8 V).
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
No connect Do not connect to this pin.
GND Ground.
No connect Do not connect to this pin.
No connect Do not connect to this pin.
Digital video input Digital Video Input Bus[35:0].
Digital video input Digital Video Input Bus[35:0].
Digital video input Digital Video Input Bus[35:0].
Digital video input Digital Video Input Bus[35:0].
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
No connect Do not connect to this pin.
Power 1 PLL Power Supply (1.8 V). This pin is a voltage regulator output. Connect a
decoupling capacitor between this pin and ground.
No connect Do not connect to this pin.
No connect Do not connect to this pin.
Digital video input Digital Video Input Bus[35:0].
Digital video input Digital Video Input Bus[35:0].
Digital video input Digital Video Input Bus[35:0].
Digital video input Digital Video Input Bus[35:0].
GND Ground.
GND Ground.
GND Ground.
