Function
gamut_packet_id[7:0]
0xxxxxxx
1xxxxxxx
Note: The packet type values and corresponding packets should not be programmed in the packet type values registers. The general
control packet (0x03) is always processed internally and cannot be stored in the packet/InfoFrame registers in the InfoFrame Map.

5.12. HDMI SECTION RESET STRATEGY

The following reset strategy is implemented for the HDMI section:
• Global chip reset – This means the ADV8003 Serial Video Rx core can be reset using the
reset is triggered by asserting the RESET pin to a low level. The HDMI section is reset when a global reset is triggered.
•
Loss of TMDS clock or 5 V signal reset – A loss of TMDS clock or 5 V signal to the Serial Video Rx resets the entire Serial Video
Rx section. The loss of a 5 V signal condition is discarded if
• DVI mode reset – The packet processing block, including InfoFrame memory, is held in reset when the Serial Video Rx
processes a DVI stream.
Rev. B, August 2013
Description
Packet type value of packet stored in InfoFrame Map, Address 0xC4 to 0xDF
Packet type value of InfoFrame stored in InfoFrame Map, Address 0xC4 to 0xDF
dis_cable_det_rst is set high.
244
ADV8003 Hardware Manual
rx_reset or main_reset. A global chip
