Function
exosd_ddr_yc_swap
0 
1
exosd_ddr_edge_sel, IO Map, Address 0x1B6A[3]
This bit is used to select which edge the first sample of DDR data is latched on.
Function
exosd_ddr_edge_sel
0 
1
Using the pixel clock as a reference, ADV8003 expects the Y sample on a rising edge and then a chroma sample on the falling edge. When
exosd_ddr_yc_swap
is set, ADV8003 expects a chroma sample on the rising edge and the Y sample on the falling edge.
exosd_swap_cb_cr_422
can be used to swap the order of the chroma data. By default, ADV8003 expects a sequence of Cb, Cr, Cb, Cr...
When
exosd_swap_cb_cr_422
exosd_swap_cb_cr_422, IO Map, Address 0x1B69[7]
This bit is used to swap the order of the C data when decoding 4:2:2 data.
Function
exosd_swap_cb_cr_422
0 
1
exosd_ps444_r444_conv
is used to convert from pseudo 444 video data to real 444. All processing occurs in the ADV8003 in 4:4:4 mode.
Therefore, if video input to the device is not in this format, it must be first converted to 4:4:4. Setting this bit to 1 converts video data to
4:4:4.
exosd_ps444_r444_conv, IO Map, Address 0x1B69[6]
This bit is used to convert 4:2:2 data to pseudo 444 or to real 444.
Function
exosd_ps444_r444_con
v
0 
1
exosd_rev_bus
is used to reverse the order of the video TTL input. By default, this is set to non reversed.
exosd_rev_bus, IO Map, Address 0x1B6B[4]
This bit is used to reverse the input video bus, i.e. D[23:0] -> D[0:23].
Function
exosd_rev_bus
0 
1
exosd_hs_pol,
exosd_vs_pol
Rev. B, August 2013
Description
Y on rising edge of clock
C on rising edge of clock
Description
Posedge data first
Negedge data first
is set, ADV8003 expects a sequence of Cr, Cb, Cr, Cb....
Description
Cb/Cr decoding
Cr/Cb decoding
Description
Nothing done.
Pseudo444 to Real 444 conversion.
Description
Reverse the pin mapping on the OSD bus
Use the OSD bus as it comes from the pins
and
exosd_de_pol
configure the polarity of the input video timing signals. These must be set depending on
