APPENDIX E

UNUSED PIN LIST

Location Mnemonic
A1 OSD_IN[23]/EXT_DIN[7]
A2 OSD_DE
A3 OSD_CLK/EXT_CLK
A4 AUD_IN[1]
A5 AUD_IN[2]
A6 AUD_IN[5]
A7 ARC2_OUT
A8 MOSI1
A9 SCK2
A10
CS2
A11 RESET
A12 XTALN
A13 PVDD2
A14 NC
A15 NC
A16 CVDD1
A17 RX_CN
A18 RX_0N
A19 RX_1N
A20 RX_2N
A21 CVDD1
A22 RSET1
A23 VREF
B1 OSD_IN[21]/EXT_DIN[5]
B2 OSD_IN[22]/EXT_DIN[6]
B3 OSD_VS
B4 AUD_IN[0]
Rev. B, August 2013
Type Description if Unused
OSD video Connect this pin to ground through a
input/ 4.7kΩ resistor.
miscellaneous
digital
OSD video Connect this pin to ground through a
sync 4.7kΩ resistor.
OSD video Connect this pin to ground through a
sync 4.7kΩ resistor.
Audio input Connect this pin to ground through a
4.7kΩ resistor.
Audio input Connect this pin to ground through a
4.7kΩ resistor.
Audio input Connect this pin to ground through a
4.7kΩ resistor.
Audio output Connect this pin to ground through a
4.7kΩ resistor.
Serial port Connect this pin to ground through a
control 4.7kΩ resistor.
Serial port Connect this pin to ground through a
control 4.7kΩ resistor.
Serial port Connect this pin to ground through a
control 4.7kΩ resistor.
Miscellaneous This pin must be connected.
digital
Miscellaneous This pin must be connected.
digital
Power PLL Digital Supply Voltage (1.8 V
No connect Float this pin.
No connect Float this pin.
Power Comparator Supply Voltage (1.8 V).
Rx input Float this pin.
Rx input Float this pin.
Rx input Float this pin.
Rx input Float this pin.
Power Comparator Supply Voltage (1.8 V).
Miscellaneous Float this pin.
analog
1
Miscellaneous Float this pin.
analog
OSD video Connect this pin to ground through a
input/ 4.7kΩ resistor.
miscellaneous
digital
OSD video Connect this pin to ground through a
input/ 4.7kΩ resistor.
miscellaneous
digital
OSD video Connect this pin to ground through a
sync 4.7kΩ resistor.
Audio input Connect this pin to ground through a
).
403
ADV8003 Hardware Manual
Pin Type
Bi-directional digital IO
Bi-directional digital IO
Bi-directional digital IO
Digital input
Digital input
Digital input
Digital output
Digital output
Digital output
Digital output
N/A
N/A
N/A
Digital output
Digital output
N/A
Digital input
Digital input
Digital input
Digital input
N/A
Analog input
Analog input
Bi-directional digital IO
Bi-directional digital IO
Bi-directional digital IO
Digital input
