Table 5. ADV8003KBCZ-7T Pin Function Descriptions
Pin
No. Mnemonic
A1 OSD_IN[23]/EXT_DIN[7
]
A2 OSD_DE
A3 OSD_CLK/EXT_CLK
A4 TEST4
A5 TEST5
A6 TEST6
A7 TEST7
A8 MOSI1
A9 SCK2
A10
CS2
A11 RESET
A12 XTALN
A13 PVDD2
A14 NC
A15 NC
A16 CVDD1
A17 RX_CN
A18 RX_0N
A19 RX_1N
A20 RX_2N
A21 CVDD1
A22 NC
A23 NC
B1 OSD_IN[21]/EXT_DIN[5
]
B2 OSD_IN[22]/EXT_DIN[6
]
B3 OSD_VS
B4 TEST8
B5 TEST9
B6 TEST10
B7 TEST11
B8 MISO1
B9 MOSI2
B10 MISO2
B11 ALSB
B12 XTALP
B13 PVDD1
B14 NC
B15 NC
B16 GND
B17 RX_CP
B18 RX_0P
B19 RX_1P
Rev. B, August 2013
Type Description
OSD video input/ External OSD Video Pixel Input Port (OSD_IN[23])/Additional TTL Input for
miscellaneous digital External CCIR 656 Video Data (EXT_DIN[7]).
OSD video sync Data Enable for the OSD Input Port.
OSD video sync Pixel Clock for the OSD Input Port (OSD_CLK)/Pixel Clock for External Video
Data (EXT_CLK).
Miscellaneous digital Test Pin. Connect this pin to Ground through a 4.7 kΩ resistor.
Miscellaneous digital Test Pin. Connect this pin to Ground through a 4.7 kΩ resistor.
Miscellaneous digital Test Pin. Connect this pin to Ground through a 4.7 kΩ resistor.
Miscellaneous digital Test Pin. Connect this pin to Ground through a 4.7 kΩ resistor.
Serial port control Master Out Slave In (Serial Port 1). Serial Port 1 is used for OSD control.
Serial port control Serial Clock (Serial Port 2). Serial Port 2 is used for the external flash ROM.
Serial port control Chip Select (Serial Port 2). Serial Port 2 is used for the external flash ROM.
Miscellaneous digital Reset Pin for the ADV8003.
Miscellaneous digital Crystal Input.
1
Power PLL Digital Supply Voltage (1.8 V).
No connect Do not connect to this pin.
No connect Do not connect to this pin.
Power Comparator Supply Voltage (1.8 V).
Rx input Rx Clock Complement Input.
Rx input Rx Channel 0 Complement Input.
Rx input Rx Channel 1 Complement Input.
Rx input Rx Channel 2 Complement Input.
Power Comparator Supply Voltage (1.8 V).
No connect Do not connect to this pin.
No connect Do not connect to this pin.
OSD video input/ External OSD Video Pixel Input Port (OSD_IN[21])/Additional TTL Input for
miscellaneous digital External CCIR 656 Video Data (EXT_DIN[5]).
OSD video input/ External OSD Video Pixel Input Port (OSD_IN[22])/Additional TTL Input for
miscellaneous digital External CCIR 656 Video Data (EXT_DIN[6]).
OSD video sync Vertical Sync for the OSD Input Port.
Miscellaneous digital Test Pin. Connect this pin to Ground through a 4.7 kΩ resistor.
Miscellaneous digital Test Pin. Connect this pin to Ground through a 4.7 kΩ resistor.
Miscellaneous digital Test Pin. Connect this pin to Ground through a 4.7 kΩ resistor.
Miscellaneous digital Test Pin. Connect this pin to Ground through a 4.7 kΩ resistor.
Serial port control Master In Slave Out (Serial Port 1). Serial Port 1 is used for OSD control.
Serial port control Master Out Slave In (Serial Port 2). Serial Port 2 is used for the external flash
ROM.
Serial port control Master In Slave Out (Serial Port 2). Serial Port 2 is used for the external flash
ROM.
I 2 C control Sets LSB of ADV8003 I
Miscellaneous digital 1 ADV8003 Crystal Input.
Power PLL Analog Supply Voltage (1.8 V).
No connect Do not connect to this pin.
No connect Do not connect to this pin.
GND Ground.
Rx input Rx Clock True Input.
Rx input Rx Channel 0 True Input.
Rx input Rx Channel 1 True Input.
2 C address (0x18 with LSB low, 0x1A with LSB high).
