Analog Devices ADV8003 Hardware Manual page 413

Location Mnemonic
AA2 GND
AA3 GND
AA4 DDR_ DQS[2]
AA5 DDR_DQ[26]
AA6 DVDD_DDR
AA7 DDR_ DQS[3]
AA8 NC/GND
AA9 DDR_A[8]
AA10 DVDD_DDR
AA11 DDR_A[2]
AA12 GND
AA13 DDR_ CS
AA14 DVDD_DDR
AA15 DDR_CK
AA16 GND
AA17 DDR_DQ[11]
AA18 DVDD_DDR
AA19 DDR_DM[1]
AA20 DDR_DM[0]
AA21 GND
AA22 GND
AA23 DDR_DQ[3]
AB1 DDR_DQ[21]
AB2 DDR_DQ[19]
AB3 DDR_DQ[17]
AB4 DDR_DM[2]
AB5 DDR_DQ[30]
AB6 DDR_DM[3]
AB7 DDR_DQ[31]
AB8 DDR_DQ[29]
AB9 DDR_A[12]
AB10 DDR_A[6]
AB11 DDR_A[3]
AB12 DDR_A[0]
AB13 DDR_BA[0]
AB14 DDR_ RAS
AB15 DDR_CKE
Rev. B, August 2013
Type Description if Unused
4.7kΩ resistor.
GND Ground.
GND Ground.
DDR interface Connect this pin to ground through a
4.7kΩ resistor.
DDR interface Connect this pin to ground through a
4.7kΩ resistor.
Power DDR Interface Supply (1.8 V).
DDR interface Connect this pin to ground through a
4.7kΩ resistor.
No For New ADV8003 Designs, Float this
connect/GND pin. For Designs That Must Maintain
Consistency with ADV8003, this Pin can
be Grounded.
DDR interface Float this pin.
Power DDR Interface Supply (1.8 V).
DDR interface Float this pin.
GND Ground.
DDR interface Float this pin.
Power DDR Interface Supply (1.8 V).
DDR interface Float this pin.
GND Ground.
DDR interface Connect this pin to ground through a
4.7kΩ resistor.
Power DDR Interface Supply (1.8 V).
DDR interface Float this pin.
DDR interface Float this pin.
GND Ground.
GND Ground.
DDR interface Connect this pin to ground through a
4.7kΩ resistor.
DDR interface Connect this pin to ground through a
4.7kΩ resistor.
DDR interface Connect this pin to ground through a
4.7kΩ resistor.
DDR interface Connect this pin to ground through a
4.7kΩ resistor.
DDR interface Float this pin.
DDR interface Connect this pin to ground through a
4.7kΩ resistor.
DDR interface Float this pin.
DDR interface Connect this pin to ground through a
4.7kΩ resistor.
DDR interface Connect this pin to ground through a
4.7kΩ resistor.
DDR interface Float this pin.
DDR interface Float this pin.
DDR interface Float this pin.
DDR interface Float this pin.
DDR interface Float this pin.
DDR interface Float this pin.
DDR interface Float this pin.
413
ADV8003 Hardware Manual
Pin Type
N/A
N/A
Bi-directional digital IO
Bi-directional digital IO
N/A
Bi-directional digital IO
N/A
Digital output
N/A
Digital output
N/A
Digital output
Digital output
N/A
Bi-directional digital IO
N/A
Digital output
Digital output
N/A
N/A
Bi-directional digital IO
Bi-directional digital IO
Bi-directional digital IO
Bi-directional digital IO
Digital output
Bi-directional digital IO
Digital output
Bi-directional digital IO
Bi-directional digital IO
Digital output
Digital output
Digital output
Digital output
Digital output
Digital output
Digital output
