Audio Sample Packets; Table 63: Recommended N And Expected Cts Values For 44.1 Khz And Multiples; Table 64: Recommended N And Expected Cts Values For 48 Khz And Multiples - Analog Devices ADV8003 Hardware Manual

Pixel Clock (MHz)
25.2 / 1.001
25.2
27
27 * 1.001
54
54 * 1.001
74.25 / 1.001
74.25
148.5 / 1.001
148.5
Other
Pixel Clock (MHz)
25.2 / 1.001
25.2
27
27 * 1.001
54
54 * 1.001
74.25 / 1.001
74.25
148.5 / 1.001
148.5
Other

6.11.4. Audio Sample Packets

By setting audioif_cc[2:0]
I2S can be routed to different subpackets using the following fields:
• subpkt0_l_src
• subpkt0_r_src
• subpkt1_l_src
• subpkt1_r_src
• subpkt2_l_src
• subpkt2_r_src
• subpkt3_l_src
• subpkt3_r_src
The audioif_ca[7:0] must be set to a speaker mapping that corresponds to the I2S input stream to subpacket routing. Using SPDIF has a
default setting of two channels.
The audio packets use the channel status format conforming to the IEC 60958 specification. When the part is configured to receive an I2S
stream, the information sent in the channel status fields is provided by the following fields:
• cr_bit
•
a_info
• clk_acc
•
category_code
Rev. B, August 2013

Table 63: Recommended N and Expected CTS Values for 44.1 kHz and Multiples

44.1kHz
N CTS
7007 31250
6272 28000
6272 30000
6272 30030
6272 60000
6272 60060
17836 234375
6272 82500
8918 234375
6272 16500
6272 Measured

Table 64: Recommended N and Expected CTS Values for 48 kHz and Multiples

48 kHz
N CTS
6864 28125
6144 25200
6144 27000
6144 27027
6144 54000
6144 54054
11648 140625
6144 74250
5824 140625
6144 148500
6144 Measured
to a value greater then 2 (that is, 3 channel or more), the eight channel audio packet format will be used. The
88.2 kHz
N CTS
14014 31250
12544 28000
12544 30000
12544 30030
12544 60000
12544 60060
35672 234375
12544 82500
17836 234375
12544 16500
12544 Measured
96 kHz
N CTS
13728 28125
12288 25200
12288 27000
12288 27027
12288 54000
12288 54054
35672 140625
12288 74250
17836 140625
12288 148500
12288 Measured
275
ADV8003 Hardware Manual
176.4 kHz
N CTS
28028 31250
25088 28000
25088 30000
25088 30030
25088 60000
25088 60060
71344 234375
25088 82500
35672 234375
25088 16500
25088 Measured
192 kHz
N CTS
27456 28125
24576 25200
24576 27000
24576 27027
24576 54000
24576 54054
46592 140625
24576 74250
23296 140625
24576 148500
24576 Measured
