Analog Devices ADV8003 Hardware Manual page 31

Pin
Mnemonic
No.
W21 PVDD6
W22 AVDD3
W23 NC
Y1 P[0]
Y2 P[1]
Y3 DDR_DQS[2]
Y4 GND
Y5 DDR_DQ[23]
Y6 DVDD_DDR
Y7 DDR_DQS[3]
Y8 GND
Y9 DDR_A[11]
Y10 DVDD_DDR
Y11 DDR_A[4]
Y12 GND
Y13 DDR_CAS
Y14 DVDD_DDR
Y15 DDR_ CK
Y16 GND
Y17 DDR_DQ[9]
Y18 DVDD_DDR
Y19 DDR_DQ[14]
Y20 GND
Y21 DDR_DQ[6]
Y22 PVDD_DDR
Y23 GND
AA1 DDR_DQ[18]
AA2 GND
AA3 GND
AA4 DDR_DQS[2]
AA5 DDR_DQ[26]
AA6 DVDD_DDR
AA7
DDR_DQS[3]
AA8 NC/GND
AA9 DDR_A[8]
AA10 DVDD_DDR
AA11 DDR_A[2]
AA12 GND
AA13 DDR_ CS
AA14 DVDD_DDR
AA15 DDR_CK
AA16 GND
AA17 DDR_DQ[11]
AA18 DVDD_DDR
AA19 DDR_DM[1]
Rev. B, August 2013
Type Description
digital
Power HDMI Tx PLL Power Supply (1.8 V). This pin is a voltage regulator output. Connect a
1
decoupling capacitor between this pin and ground.
Power HDMI Analog Power Supply (1.8 V).
No connect Do not connect to this pin.
Digital video input Digital Video Input Bus[35:0].
Digital video input Digital Video Input Bus[35:0].
DDR interface Data Strobe for DDR Data Byte[23:16].
GND Ground.
DDR interface Data Line. Interface to external RAM data lines.
Power DDR Interface Supply (1.8 V).
DDR interface Data Strobe for DDR Data Byte[31:24].
GND Ground.
DDR interface Address Line. Interface to external RAM address lines.
Power DDR Interface Supply (1.8 V).
DDR interface Address Line. Interface to external RAM address lines.
GND Ground.
DDR interface Column Address Strobe for DDR Memory.
Power DDR Interface Supply (1.8 V).
DDR interface DDR Memory Clock. Interface to external DDR RAM clock lines.
GND Ground.
DDR Interface Data Line. Interface to external RAM data lines.
Power DDR Interface Supply (1.8 V).
DDR interface Data Line. Interface to external RAM data lines.
GND Ground.
DDR interface Data Line. Interface to external RAM data lines.
Power DDR Interface PLL Supply (1.8 V).
GND Ground.
DDR interface Data Line. Interface to external RAM data lines.
GND Ground.
GND Ground.
DDR interface Data Strobe for DDR Data Byte[23:16].
DDR interface Data Line. Interface to external RAM data lines.
Power DDR Interface Supply (1.8 V).
DDR interface Data Strobe for DDR Data Byte[31:24].
No connect/GND For new ADV8003 designs, do not connect to this pin. For designs that must
maintain consistency with the ADV8002, this pin can be grounded.
DDR interface Address Line. Interface to external RAM address lines.
Power DDR Interface Supply (1.8 V).
DDR interface Address Line. Interface to external RAM address lines.
GND Ground.
DDR interface DDR Chip Select. Interface to external DDR RAM chip selects.
Power DDR Interface Supply (1.8 V).
DDR interface DDR Memory Clock. Interface to external DDR RAM clock lines.
GND Ground.
DDR interface Data Line. Interface to external RAM data lines.
Power DDR Interface Supply (1.8 V).
DDR interface Data Mask for Data Lines[15:8].
31
