Analog Devices ADV8003 Hardware Manual page 62

N10 GND
N11 GND
N12 GND
N13 GND
N14 GND
N15 GND
N16 GND
N17 GND
N20 NC
N21 PVDD5
N22 AVDD3
N23 NC
P1 P[20]
P2 P[21]
P3 P[22]
P4 P[23]
P7 DVDD
P8 GND
P9 GND
P10 GND
P11 GND
P12 GND
P13 GND
P14 GND
P15 GND
P16 GND
P17 DVDD
P20 NC
P21 GND
P22 NC
P23 NC
R1 P[16]
R2 P[17]
R3 P[18]
R4 P[19]
R7 GND
R8 GND
R9 GND
R10 GND
R11 GND
R12 GND
R13 GND
R14 GND
R15 GND
R16 GND
R17 GND
R20 NC
R21 GND
R22 NC
Rev. B, August 2013
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
No connect Do not connect to this pin.
Power PLL Power Supply (1.8 V). This pin is a voltage regulator output. Connect a
1
decoupling capacitor between this pin and ground.
Power HDMI Analog Power Supply (1.8 V).
No connect Do not connect to this pin.
Digital video input Digital Video Input Bus[35:0].
Digital video input Digital Video Input Bus[35:0].
Digital video input Digital Video Input Bus[35:0].
Digital video input Digital Video Input Bus[35:0].
Power Digital Power Supply (1.8 V).
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
Power Digital Power Supply (1.8 V).
No connect Do not connect to this pin.
GND Ground.
No connect Do not connect to this pin.
No connect Do not connect to this pin.
Digital video input Digital Video Input Bus[35:0].
Digital video input Digital Video Input Bus[35:0].
Digital video input Digital Video Input Bus[35:0].
Digital video input Digital Video Input Bus[35:0].
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
No connect Do not connect to this pin.
GND Ground.
No connect Do not connect to this pin.
