Analog Devices ADV8003 Hardware Manual page 405

Location Mnemonic
C13 GND
C14 NC
C15 NC
C16 RX_HPD
C17 AVDD1
C18 GND
C19 GND
C20 AVDD1
C21 AVDD1
C22 DAC5
C23 DAC6
D1 OSD_IN[16]/EXT_DIN[0]
D2 OSD_IN[17]/EXT_DIN[1]
D3 OSD_IN[18]/EXT_DIN[2]
D4 GND
D5 DVDD_IO
D6 MCLK
D7 SDA
D8
CS1
D9 GND
D10 INT1
D11 INT2
D12 DVDD_IO
D13 TEST1
D14 NC
D15 NC
D16 RX_5V
D17 NC
D18 NC
D19 RTERM
D20 AVDD2
D21 AVDD2
D22 DAC1
Rev. B, August 2013
Type Description if Unused
GND Ground.
No connect Float this pin.
No connect Float this pin.
Rx input Float this pin.
Power Serial Video Rx Inputs Analog Supply
(3.3 V).
GND Ground.
GND Ground.
Power Serial Video Rx Inputs Analog Supply
(3.3 V).
Power Serial Video Rx Inputs Analog Supply
(3.3 V).
Analog video Float this pin.
output
Analog video Float this pin.
output
OSD video Connect this pin to ground through a
input/ 4.7kΩ resistor.
miscellaneous
digital
OSD video Connect this pin to ground through a
input/ 4.7kΩ resistor.
miscellaneous
digital
OSD video Connect this pin to ground through a
input/ 4.7kΩ resistor.
miscellaneous
digital
GND Ground.
Power Digital Interface Supply (3.3 V).
Audio input Connect this pin to ground through a
4.7kΩ resistor.
I C control This pin must be connected.
2
Serial port Connect this pin to ground through a
control 4.7kΩ resistor.
GND Ground.
Miscellaneous Connect this pin to ground through a
digital 4.7kΩ resistor.
Miscellaneous Connect this pin to ground through a
digital 4.7kΩ resistor.
Power Digital Interface Supply (3.3 V).
Miscellaneous Float this pin.
digital
No connect Float this pin.
No connect Float this pin.
Rx input Connect this pin to +5V.
No connect Float this pin.
No connect Float this pin.
Serial Video Float this pin.
Rx input
Power Encoder Analog Power Supply (3.3 V).
Power Encoder Analog Power Supply (3.3 V).
Analog video Float this pin.
405
ADV8003 Hardware Manual
Pin Type
N/A
Digital output
Digital output
Digital output
N/A
N/A
N/A
N/A
N/A
Analog output
Analog output
Bi-directional digital IO
Bi-directional digital IO
Bi-directional digital IO
N/A
N/A
Digital input
N/A
Digital input
N/A
Digital output
Digital output
N/A
Digital output
Digital output
Digital output
Digital input
Digital input
Digital input
Analog input
N/A
N/A
Analog output
