svsp_fieldbuffer0_addr[31:0], Secondary VSP Map, Address 0xE600[7:0]; Address 0xE601[7:0]; Address 0xE602[7:0]; Address 0xE603[7:0]
This signal is used to set the start address of frame buffer 0. The software should arrange memory space properly, avoiding conflict
between different buffers.
Function
svsp_fieldbuffer0_addr[
31:0]
0x00000000
0xXXXXXXXX
svsp_fieldbuffer1_addr[31:0], Secondary VSP Map, Address 0xE604[7:0]; Address 0xE605[7:0]; Address 0xE606[7:0]; Address 0xE607[7:0]
This signal is used to set the start address of frame buffer 1. The software should arrange memory space properly, avoiding conflict
between different buffers.
Function
svsp_fieldbuffer1_addr[
31:0]
0x00000000
0xXXXXXXXX
svsp_fieldbuffer2_addr[31:0], Secondary VSP Map, Address 0xE608[7:0]; Address 0xE609[7:0]; Address 0xE60A[7:0]; Address 0xE60B[7:0]
This signal is used to set the start address of frame buffer 2. The software should arrange memory space properly, avoiding conflict
between different buffers.
Function
svsp_fieldbuffer2_addr[
31:0]
0x00000000
0xXXXXXXXX
svsp_fieldbuffer3_addr[31:0], Secondary VSP Map, Address 0xE60C[7:0]; Address 0xE60D[7:0]; Address 0xE60E[7:0]; Address
0xE60F[7:0]
This signal is used to set the start address of frame buffer 3. The software should arrange memory space properly, avoiding conflict
between different buffers.
Function
svsp_fieldbuffer3_addr[
31:0]
0x00000000
0xXXXXXXXX
svsp_fieldbuffer4_addr[31:0], Secondary VSP Map, Address 0xE664[7:0]; Address 0xE665[7:0]; Address 0xE666[7:0]; Address 0xE667[7:0]
This signal is used to set the start address of field/frame buffer 4. The software should arrange memory space properly, avoiding conflict
between different buffers.'
Rev. B, August 2013
Description
Default
Start address of frame buffer 0
Description
Default
Start address of frame buffer 1
Description
Default
Start address of frame buffer 2
Description
Default
Start address of frame buffer 3
186
