7.5.3.

Using CEC Module as Follower

Figure 103 shows the algorithm that can be implemented in the host processor controlling the ADV8003 in order to use the CEC module
as a follower.
CEC_RX_READY_INT
N
Read the buffer
associated with
timestamp = 0b01
maximum
timestamp
Rev. B, August 2013
N
=001 ?
Y
Reached
N
?
Y

Figure 103: Using CEC Module as Follower

START
(wait for interrupt)
CEC_RX_READY_INT
=010 ?
Y
Read
BUF0_TIMESTAMP
BUF1_TIMESTAMP
BUF2_TIMESTAMP
and note the maximum value
Read the buffer
associated with
timestamp = 0b10
Reached
maximum
timestamp
?
Y
Set the appropriate clear bits
CEC_RX_READY_INT
corresponding to the buffers
that have been read.
END
304
CEC_RX_READY_INT
=100 ?
Y
Read the buffer
associated with
timestamp = 0b11
N
