Analog Devices ADV8003 Hardware Manual page 39

Pin
Mnemonic
No.
J14 GND
J15 GND
J16 GND
J17 DVDD
J20 DDC1_SDA
J21 GND
J22 TX1_1+
J23 TX1_1−
K1 VS
K2 PCLK
K3 DVDD_IO
K4 DVDD_IO
K7 GND
K8 GND
K9 GND
K10 GND
K11 GND
K12 GND
K13 GND
K14 GND
K15 GND
K16 GND
K17 GND
K20 DDC1_SCL
K21 GND
K22 TX1_0+
K23 TX1_0−
L1 P[32]
L2 P[33]
L3 P[34]
L4 P[35]
L7 DVDD
L8 GND
L9 GND
L10 GND
L11 GND
L12 GND
L13 GND
L14 GND
L15 GND
L16 GND
L17 GND
L20 HPD_TX1
L21 GND
L22 TX1_C+
L23 TX1_C−
Rev. B, August 2013
Type Description
GND Ground.
GND Ground.
GND Ground.
Power Digital Power Supply (1.8 V).
HDMI Tx1 HDCP Slave Serial Data for HDMI Tx1. This pin is open drain; use a 2 kΩ resistor to
connect this pin to the HDMI Tx 5 V supply.
GND Ground.
HDMI Tx1 HDMI1 Channel 1 True Output.
HDMI Tx1 HDMI1 Channel 1 Complementary Output.
Digital video sync Vertical Sync for Digital Input Video.
Digital video sync Pixel Clock for Digital Input Video.
Power Digital Interface Supply (3.3 V).
Power Digital Interface Supply (3.3 V).
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
HDMI Tx1 HDCP Slave Serial Clock for HDMI Tx1. This pin is open drain; use a 2 kΩ resistor to
connect this pin to the HDMI Tx 5 V supply.
GND Ground.
HDMI Tx1 HDMI1 Channel 0 True Output.
HDMI Tx1 HDMI1 Channel 0 Complementary Output.
Digital video input Digital Video Input Bus[35:0].
Digital video input Digital Video Input Bus[35:0].
Digital video input Digital Video Input Bus[35:0].
Digital video input Digital Video Input Bus[35:0].
Power Digital Power Supply (1.8 V).
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
GND Ground.
HDMI Tx1 Hot Plug Assert Signal Input for HDMI Tx1.
GND Ground.
HDMI Tx1 HDMI1 Clock True Output.
HDMI Tx1 HDMI1 Clock Complementary Output.
39
ADV8003 Hardware Manual
