LRCLK
SCLK
DATA
LRCLK
SCLK
DATA
6.11.2.2.

SPDIF Audio

The ADV8003 can receive two channel LPCM or encoded multichannel audio up to a 192 kHz sampling rate via the SPDIF input
interface. The detected sampling frequency for the SPDIF input stream can be read via the
It is possible to set the sampling audio sampling frequency of the input SPDIF stream. This is done by setting
1. When audio_sampling_freq_sel
is not extracted from the input SPDIF stream and must be programmed in the
used in the Audio Sample packets sent to the downstream sink can be read from the
The ADV8003 is capable of accepting SPDIF with or without an audio master clock input to through the input pin MCLK. When the
ADV8003 does not receive an audio master clock, the ADV8003 uses the bit clock input via the SCLK pin to internally generate an audio
master clock and determine the CTS value.
spdif_sf[3:0], TX2 Main Map, Address 0xF404[7:4] (Read Only)
This signal is used to readback the audio sampling frequency from the SPDIF channel.
Rev. B, August 2013
LEFT
LSB MSB
right left
16 Clock Slots

Figure 94: Timing for I2S Stream in 32-bit Mode

LEFT
MSB
16 Clock Slots

Figure 95: Timing for I2S Stream in Left or Right-Justified and 32-bit Modes

is set to 1, the sampling frequency used to determine the pixel repetition factor (refer to
RIGHT
LSB MSB
left right
16 Clock Slots
RIGHT
LSB MSB
spdif_sf[3:0]
i2s_sf[3:0] field. Note that the sampling frequency that is
spdif_sf[3:0]
270
ADV8003 Hardware Manual
LSB
left
LSB
16 Clock Slots
field.
audio_sampling_freq_sel
field.
to
Section 6.11.1)
