Pin
Mnemonic
No.
T9
GND
T10
GND
T11
GND
T12
GND
T13
GND
T14
GND
T15
GND
T16
GND
T17
GND
T20
HPD_TX2
T21
GND
T22
TX2_0+
T23
TX2_0−
U1
P[10]
U2
P[11]
U3
P[12]
U4
P[13]
U7
GND
U8
GND
U9
DVDD
U10
GND
U11
GND
U12
DVDD
U13
GND
U14
GND
U15
DVDD
U16
GND
U17
GND
U20
R_TX2
U21
GND
U22
TX2_C+
U23
TX2_C−
V1
P[6]
V2
P[7]
V3
P[8]
V4
P[9]
V20
GND
V21
PVDD6
V22
HEAC_2+
V23
HEAC_2−
W1
P[2]
W2
P[3]
W3
P[4]
W4
P[5]
W20
TEST3
Rev. B, August 2013
Type
Description
GND
Ground.
GND
Ground.
GND
Ground.
GND
Ground.
GND
Ground.
GND
Ground.
GND
Ground.
GND
Ground.
GND
Ground.
HDMI Tx2
Hot Plug Assert Signal Input for HDMI Tx2.
GND
Ground.
HDMI Tx2
HDMI2 Channel 0 True Output.
HDMI Tx2
HDMI2 Channel 0 Complementary Output.
Digital video input
Digital Video Input Bus[35:0].
Digital video input
Digital Video Input Bus[35:0].
Digital video input
Digital Video Input Bus[35:0].
Digital video input
Digital Video Input Bus[35:0].
GND
Ground.
GND
Ground.
Power
Digital Power Supply (1.8 V).
GND
Ground.
GND
Ground.
Power
Digital Power Supply (1.8 V).
GND
Ground.
GND
Ground.
Power
Digital Power Supply (1.8 V).
GND
Ground.
GND
Ground.
HDMI Tx2
Sets internal reference currents. Place a 470 Ω resistor (1% tolerance) between this
1
pin and ground. The external resistor should be placed as close as possible to the
ADV8003.
GND
Ground.
HDMI Tx2
HDMI2 Clock True Output.
1
HDMI Tx2
HDMI2 Clock Complementary Output.
1
Digital video input
Digital Video Input Bus[35:0].
Digital video input
Digital Video Input Bus[35:0].
Digital video input
Digital Video Input Bus[35:0].
Digital video input
Digital Video Input Bus[35:0].
GND
Ground.
Power
HDMI Tx PLL Power Supply (1.8 V). This pin is a voltage regulator output. Connect a
1
decoupling capacitor between this pin and ground.
HDMI Tx2
HDMI Tx2 HEC+ from HDMI Connector.
HDMI Tx2
HDMI Tx2 HEC− from HDMI Connector.
Digital video input
Digital Video Input Bus[35:0].
Digital video input
Digital Video Input Bus[35:0].
Digital video input
Digital Video Input Bus[35:0].
Digital video input
Digital Video Input Bus[35:0].
Miscellaneous
Test Pin. Connect this pin to Ground through a 0.1 uF capacitor.
30
ADV8003 Hardware Manual
